What seperates Max Span from other shutters
- Aesthetics: Double coated + lacquer for abrasion resistant finish
- Strength: 77mm x 18.5mm foam filled high quality aluminium profiles engineered for extra strength
- Excellent for: home & business security, light blocking, noise reduction, climate control, energy savings,
- Good for: glare reduction light control and light blocking
- Other shutters to consider: Patiomate, Fortress
Important Details
- Maximum Height: 3000mm
- Maximum Width: 5900mm (including the side tracks)
- 77mm x 18.5mm Aluminium Interlocking slats
- Full specifications in the table below
Benefits
- Up to 85% noise reduction
- Up to 15° cooler in summer
- Up to 15° warmer in winter
- Up to 98% light block out
- Up to 45% more energy efficient
- Secure, built-in locking mechanism
- Eliminates condensation
- Reduces glare
- Rust prevention: 90% components aluminium
Shutter Details
- Maximum Height: 3000mm
- Maximum Width: 5900mm (including the side tracks)
- 77mm x 18.5mm roll formed aluminium profile with polyurethane foam insulation
- Shutter guide Securing points at 300-400mm intervals
- Pelmet box securing points at 800mm intervals
- ~ 105 mm x 37 mm aluminium extended shutter guides
- ~ 106 mm x 19 mm bottom rail
- Weight per sq metre 5.5kg
Pelmet Sizes
- Max height including pelmet up to 2000mm – 250mm Pelmet Box
- Max height including pelmet up to 3200mm – 300mm Pelmet Box
Applications
- Patios
- Pergolas
- Verandas
- Alfresco
- Garage Doors
- Doors
- Doorways
- Counters
- Windows
- Bars
- Roof windows
- Built in wardrobes
- Canteens
- Cabanas
- carports
- Bay Windows
- Garden Windows
- Curved Windows
- Atriums
- Closets
- Cupboards
- Partitioning Areas
- Room Dividers
What they offer
What they offer
- Security for Medium to High risk areas
- Noise reduction
- Great protection against heat, cold
- Medium to High protection for windy areas
- Excellent for peninsula seafronts
- Internal or external installation
Patiomate Shutters are Suitable for
- Residential homes
- Patios
- Alfresco
- Garage Doors
- Pergolas
- Council Pavilions
- Shopfronts
- Offices
- Factories
- Apartments
- Flats
- Units
- Townhouses
- Multi storey buildings
- Portable buildings
- Trucks
- Vans
- Caravans
Colours
- Cream
- Clear Beige
- White
- Surfmist
- Shale Grey
- Brown
- Black
- Monument
- Silver
- Woodland Grey
Additional Information
Prices:
All rates include GST, as well as shipping charges where these are not indicated separately. Note: Discounts and/or free product offers do not apply to products purchased before or after the specified promotional period.
Placing Your Order:
The order process through our online shop consists of several steps. First, you select the desired goods by following the measure instructions or visiting How to Measure page on the website. Next, you must provide your measurements and other order data, including the billing address and delivery address (if different). As a next step, you must select the payment method. Finally, you have the option of checking all the information provided (e.g. name, address, payment method, ordered goods) and correcting it if required before sending us your order by clicking “Purchase”. We will process your order and assign an estimated delivery date upon receipt of the information. Please note that production lead times commence only when we have received the full payment. It is the customers responsibility to ensure this is paid in a timely manner.
Delivery Conditions:
Areas that are non Major Cities in the structure, or some properties/farms may incur delays in delivery. Public holidays, Easter, and Christmas can extend the delivery times by 15-20 working days. Any roller shutter that exceeds a width or height of 2200mm, or weighs more than 24kg, necessitates a commercial delivery address with a forklift access; Alternatively, it can be collected from the nearest depot.
Wiring AC Electrical Motors:
AC Electric motors need to be wired into the mains of the property by a fully qualified electrician. It is the customer’s responsibility to make sure this is done by a registered and qualified electrician.
Warranty Terms:
Visit Warranty page on the website for more information.
